| Wires (Cold Drawn) |
| |
Application :
Nails, Pins, Staples, Rivets, Safety Pins, Wedge Screen, Knitting
Filters, Sieves, Springs, Bicycle and Umbrella Spokes, Annealed wire
for Redrawing, Brushes, Strainers, Scrubbers, Cold Heading Wires,
Slings and Chains, Conveyer Belts, Steel Balls and Wall Ties. |
| |
| Diameter
(Size) |
0.70 to 6.00
mm – ((0.027 ” to 0.225 ”) |
| Diameter
Tolerance |
Diameter |
Tolerance |
0.50mm (0.0197")
to < 1.25mm (0.0492")
1.25mm (0.0492") to < 2.00mm (0.0787")
2.00mm (0.0787") to < 3.25mm (0.1280")
3.25mm (0.1280") to < 4.75mm (0.1870")
4.75mm (0.1870") to < 8.00mm (0.3150") |
+/-0.012mm (0.0005")
+/-0.015mm (0.0006")
+/-0.020mm (0.0008")
+/-0.025mm (0.0010")
+/-0.040mm (0.0015") |
| Surface
Finish |
Bright Drawn
(Matt), Bright Shiny, EPQ, Coated, Lightly Coated, De-coated |
| Tensile
Strenght |
Type |
Tensile in Kg/mm 2
|
Soft
1/4 Hard
1/2 Hard
Full Hard |
60-75
75-90
90-140
140-200 |
| Packing |
-HDPE Wrapped coils of 20 kg to 250 kgs
-Pattern laid coils on MS Carriers /
Spiders (200 kgs to 1000 kgs)
-Coils on wooden pallets (100 kgs to 800 kgs)
|
| Grades |
302, 303, 304, 304L, 316, 316L, 302HQ, 304HC, 321, 316Ti,
308LER, 309LER, 316LER, 430, 430L
|
|
| |
| |
| Wires (Cold Heading) |
| |
Application :
Surgical Items, Needles, Medical Wire, Welding Electrodes, and Filler
Wires, Kitchen Appliances, Gratings, Mats, Wire Cloth, Wire Mesh,
Wire Rope, Spectacle Frame, Watch Band, Bolts, Screws, Fasteners,
Free Cutting Wire, Weaving Wire, Lashing Wires and Music Wire. |
| |
| Condition |
Cold Drawn
Annealed and Pickled |
| Diameter
(Size) |
5mm to 17mm
(3/16 ” to 11//16 ”) |
| Diameter
Tolerance |
+/-0.050mm |
| Tensile
Strenght |
60-70 kg/mm
2 |
| Packing |
HDPE Wrapped
Coils of 300-500 kgs |
| Grades |
304, 304L,
316, 316L, 304HC, 302HQ |
|
| |
| |
|
