| Round Bars (Cold Drawn) |
| |
Application :
Machined Components, Pump Shafts, Valves, Fasteners, Machine Tools,
Dairy Equipments, Surgical & Medical Parts, Threaded Bars, Studs,
Bolts, Pins, Hinges and Handles. |
| |
| Condition |
Cold Drawn
& Polished |
Cold Drawn,
Centreless Ground & Polished |
Cold Drawn,
Centreless Ground & Polished (Strain Hardened) |
| Grades |
20, 202, 303,
304, 304L, 310, 316, 316L, 32, 410, 420, 416, 430, 431, 430F
& others |
304, 304L,
316, 316L |
| Diameter
(Size) |
2 mm to 5mm
(1/8" to 3/16") |
6mm to 22m
(1/4" to 7/8") |
10mm to 40mm
(3/8" to 1-1/2") |
| Diameter
Tolerance |
h9 (Din 671),h11
ASTM A 484 |
h9 (Din 671)
ASTM A 484
|
h9 (Din 671),h11
ASTM A 484 |
| Length |
3/4/5.6/6 meter
(12/14ft/20feet)
|
3/4/5.6/6
meter
(12/14ft/20feet) |
3/4/5.6/6
meter
(12/14ft/20feet) |
| Length
Tolerance |
-0/+200mm or
+100mm or +50mm
(-0 ”/+1 feet or +4 ” or 2 ”)
|
-0/+200mm
or
+100mm or +50mm
(-0 ”/+1 feet or +4 ” or 2 ”) |
-0/+200mm
(-0 ”/+1 feet) |
|
| |
| We can give Chamfering of 30 or 45 degrees on one
or both the ends with our dedicated chamfering machine. For Strain-Hardened
Bars, we can supply in B8(304) and B8M(316) in Class1 and Class2. |
| |
| Round Bars (Peeled/Turned) |
| |
| Condition |
Peeled, Centreless
Ground & Polished |
Peeled &
Polished |
Peeled
(Rough Turned) |
Forged,
Rough Turned |
| Grades |
20, 202, 303,
304, 304L, 310, 316, 316L, 321, 410, 420, 416, 430, 431, 430F
& others |
304, 304L,
316, 316L, 410, 416, 420, 431 |
303, 304,
304L, 316, 316L, 410, 416, 420, 431 |
| Diameter
(Size) |
20mm to 85mm
(3/4 ” to 3--1/4 ”) |
85mm to 140mm
(3-1/4 ” to 4--3/4 ”) |
25mm to 140mm
(1 ” to 5--1/2 ”) |
150mm to 400mm
(6 ” to 16 ”) |
| Diameter
Tolerance |
h9 (Din 671)
ASTM A 484 |
h11
|
K12/K13
(Din 1013) |
-0mm/+3mm
(-0 ”/+0.12 ”) |
| Length |
3/4/5.6/6 meter
(12/14ft/20feet)
|
3/4/5.6/6
meter
(12/14ft/20feet) |
3/4/5.6/6
meter
(12/14ft/20feet) |
3 meter -5
meter
10 feet -16 feet |
| Length
Tolerance |
-0/+200mm or
+100mm or +50mm
(-0 ”/+1 feet or +4 ” or 2 ”)
|
-0/+200mm
or
+100mm or +50mm
(-0 ”/+1 feet or +4 ” or 2 ”) |
-0/+1000mm
or 500mm (-0 ”/+3 feet or +2 feet) |
-0/+2 meter-
-0/+6 feet |
|
| |
| We can give superior surface finish and straightness
tolerance for Pump Shaft Quality by additional processes such as straightening,roller
burnishing,and centreless grinding.Bars can be packed in wooden boxes,with
each bar protected with plastic rings to avoid bending and scratches. |
| |
| |
|
